Built for your setup.
The power-conversion and control module for an E10 system.
Brand new
Anker SOLIX E10 Power Module
The power-conversion and control module for an E10 system.
- Output Rated Voltage: 120 / 240 VAC (Split Phase)
- Output Rated Frequency: 60Hz
- Maximum Continuous Output Power / Current (With Battery): 7,680W, 32A
$2,499.00 USD
Available to order
Need help choosing the right setup?Ask DRT ↗
SKU: A17E1141
Overview
E10 Power Module
The power-conversion and control module for an E10 system.
E10 Power Module
Product highlights
Check the connection.
Requires compatible B6000 storage; this listing is not a complete battery system.
Images show example setups. Extra equipment is included only when listed in your selected configuration. Illustrated runtime depends on test conditions and actual use.
E10 Power Module
What’s in the box
E10 power module
Standard product contents are shown below. The selected configuration lists additional bundle equipment; optional add-ons are separate.
E10 Power Module
Specifications
- Output Rated Voltage
- 120 / 240 VAC (Split Phase)
- Output Rated Frequency
- 60Hz
- Maximum Continuous Output Power / Current (With Battery)
- 7,680W, 32A
View full specifications
- Output Rated Voltage
- 120 / 240 VAC (Split Phase)
- Output Rated Frequency
- 60Hz
- Maximum Continuous Output Power / Current (With Battery)
- 7,680W, 32A
- Turbo Backup Output Power / Current (With two Batteries)
- 10,000W, 41.6A (90 Minutes)
- LRA Equivalent Ability
- 120A (1 Inverter, 1 Battery) 155A (1 Inverter, 2+ Batteries) 275A (2+ Inverters, 2+ Batteries Each)
- AC Input Port Recharging
- 1,800W, 120V / 15A * 7,680W, 240V / 32A
- AC Input Port Bypass
- 9,600W, 240V / 40A
- PV (Solar) Input
- 2x 4,500W, 30 to 450V(DC), 15A(Imp)
- DC Generator Input
- 4,500W
- Enclosure Type
- NEMA TYPE 4 (IP66)
- Operating Temperature
- -4 °F to 131 °F (-20~55°C)
- Connectivity
- Wi-Fi, Bluetooth
- Dimensions (W x H x D)
- 26.4" x 11.8" x 10.2" (670 x 300 x 260 mm)
- Weight
- 60.6lb (27.5kg)
Compatibility & setup
Requires compatible B6000 storage; this listing is not a complete battery system.
FAQ
Questions, answered.
What system is required?
Requires compatible B6000 storage; this listing is not a complete battery system.
Is this a complete home backup package?
The selected configuration lists the included equipment. Batteries, connection hardware and installation are separate unless explicitly included.
Where can I find installation instructions?
Use the official model-specific documents linked below. Have a qualified installer confirm the electrical and structural requirements.
What is included in my selected configuration?
The configuration name and order summary identify the selected main equipment and bundle items. Optional add-ons are separate and are included only when selected.
Manuals & downloads
E10 Power Module$2,499.00
